F8114 GPRS ZigBee MODEM TECHNICAL SPECIFICATION
F8114 GPRS ZigBee MODEM TECHNICAL SPECIFICATION
F8114 GPRS ZigBee MODEM is a kind of data terminal device that provides data transfer function by public GPRS and ZigBee network.
It adopts high-powered industrial 32 bits CPU and embedded real time operating system. It supports RS232, RS485 (or RS422) and ZigBee port that can conveniently and transparently connect one device to a cellular network, allowing you to connect to your existing serial and ZigBee devices with only basic configuration. It has low power consumption states in which the power consumption could be 1ower than 1mA@12VDC. It has compatible digital I/O channel, ADC, input pulse counter and pulse wave output function.
|
F8114 GPRS ZigBee MODEM Product Feature ---------------------------------------------------------------------------------------------------------------------------------
Content
| |
Cellular Module
|
Industrial cellular module
|
Standard and Band
|
EGSM900/GSM1800MHz,
GSM850/900/1800/1900MHz(optional)
Compliant to GSM phase 2/2+
GPRS class 10, class 12(optional)
|
Bandwidth
|
85.6Kbps
|
TX power
|
GSM850/900: <33dBm
GSM1800/1900: <30dBm
|
RX sensitivity
|
<-107dBm
|
ZigBee Specification
Item
|
Content
|
ZigBee Module
|
Industrial ZigBee module
|
Standard and Band
|
IEEE 802.15.4
ISM 2.4 GHz
|
Indoor/Urban Range
|
60m
90m(for enhanced version)
|
Outdoor/RF Line-of-Sight Range
|
100m
800m(for enhanced version)
|
Transmit Power
|
0dBm
22dBm (for enhanced version)
|
Bandwidth
|
250Kbps
|
Receiver Sensitivity
|
-95dBm
-104dBm(for enhanced version)
|
Network Topologies
|
Point-to-Point, Point-to-Multipoint, Peer-to-Peer and Mesh
|
Number of channels
|
16 Direct Sequence Channels
15 Direct Sequence Channels (for enhanced version)
|
Channels
|
11 to 26
11 to 25 (for enhanced version)
|
Max packge size
|
1024 Bytes
|
Hardware System
Item
|
Content
|
CPU
|
Industrial 32 bits CPU
|
FLASH
|
512KB (Extendable)
|
SRAM
|
256KB(Extendable)
|
Interface Type
Item
|
Content
|
Serial
|
1 RS232 port and 1 RS485(orRS422) port, 15KV ESD protection
Data bits: 5, 6 ,7, 8
Stop bits: 1, 1.5, 2
Parity: none, even, odd, space, mark
Baud rate: 110~230400 bps
|
Indicator
|
"Power", "ACT", "Online", "ZigBee"
|
Antenna
|
Cellular: Standard SMA female interface, 50 ohm, lighting protection(optional)
ZigBee: Standard SMA female interface, 50 ohm, lighting protection(optional)
|
SIM/UIM
|
Standard 3V/1.8V user card interface, 15KV ESD protection
|
Power
|
Terminal block interface, reverse-voltage and overvoltage protection
|
 | |
Power Input
Item
|
Content
|
Standard Power
|
DC 12V/0.5A
|
Power Range
|
DC 5~35V
|
Power Consumption
Working States
|
Power Consumption
|
Communication
|
50-90mA@12VDC；115-165mA@5VDC
|
Standby
|
25mA@12VDC；45mA@5VDC
|
Sleep
|
8mA@12VDC；18mA@5VDC
|
Timing Power Off
|
0.6mA@12VDC；1mA@5VDC
|
Physical Characteristics
Item
|
Content
|
Housing
|
Iron, providing IP30 protection
|
Dimensions
|
91x58.5x22 mm
|
Weight
|
210g
|
Environmental Limits
Item
|
Content
|
Operating Temperature
|
-25~+65ºC (-13~+149℉)
|
Extended Operating Temperature
|
-30~+75ºC (-22~+167℉)
|
Storage Temperature
|
-40~+85ºC (-40~+185℉)
|
Operating Humidity
|
95% ( unfreezing)
|
